Nice SlideSmart 535 Commercial Automatic Slide Gate Opener

The Nice SlideSmart 535 slide gate operator merges modern connectivity with precise motion control for both residential and commercial entrances. Its 24V brushless DC motor and SmartBLDC Power Module deliver quiet, controlled starts and stops while maintaining high efficiency. The SmartTouch 725 controller provides over 70 programmable settings with Bluetooth and HyNet wireless setup, simplifying adjustments and monitoring through a smartphone. Designed to move gates up to 1,500 pounds and 50 feet long, it offers standard battery backup for up to 100 cycles, or up to 450 cycles with upgraded batteries. Built and tested in the USA.

Features

• Brushless DC motor with SmartBLDC Power Module for smooth operation
• Supports gates up to 1,500 lbs and 50 ft in length
• Independent open and close speed adjustment
• SmartTouch 725 controller with 70+ configurable settings
• Bluetooth connectivity and HyNet app integration
• BlueBUS and OXI interface for Nice accessory compatibility
• Standard battery backup up to 100 cycles; extended to 450 with upgrades
• Onboard diagnostics and event log for troubleshooting
• Made in the USA from globally sourced materials

Specifications

• Duty Cycle: Continuous
• Horsepower: Equivalent to 1/2 HP
• Drive Type: 24V Brushless DC with direct drive gear train
• Rate of Travel: 0.75, 1.0, or 1.25 ft/s (23 - 38 cm/s)
• Gate Weight: Max 1,500 lbs (680 kg)
• Gate Length: Max 50 ft (15 m)
• UPS Battery Backup: Two 8Ah batteries (up to 4,000 ft travel), optional 35Ah batteries (up to 18,000 ft travel)
• Input Voltage: 115V or 208 - 230V AC, 60/50 Hz
• Operating Voltage: 24VDC
• Temperature Range: -13 to 158 Degrees F (-25 to 70 Degrees C)
• Accessory Power: 24VDC, 2A accumulative
• Communication: BlueBUS, USB, Ethernet, RS-485, Bluetooth, OXI
• Included Accessories: 30 ft corrosion-resistant chain, steel mounting brackets, photo eye, 5-ft edge sensor, and backup batteries
• Finish: Zinc-rich primer with black powder-coated chassis, high-impact copolymer cover
• UL Listing: ETL Listed (UL 325), Usage Class I - IV
• Warranty: 5-year (7-year single-family residential with registration)
