HySecurity HydraSwing 150 Swing Gate Operator (15,000 lbs Max.)

The HydraSwing 150 is HySecurity's most powerful swing gate operator, supporting gates up to 15,000 lbs. Designed for correctional facilities, ports, and critical infrastructure, it provides unmatched lifting strength and reliability. This heavy-duty system is built for extreme gate sizes and constant use.

Please Note: You will need a Drive Unit AND a Power Supply for this opener to function properly. When ordering, please also call to specify the voltage of your power supply OR you can click on the power supply and order it separately, where you can indicate the voltage. If you have any questions about what you may need, please review the order form below or Contact Us to consult with an expert. We are happy to assist. Order Form

1

Gate Opener Drive Units

HydraSwing 150 - HYDRA-SWING-150

HySecurity Drive Unit for HydraSwing 150 Automatic Swing Gate Openers

Part: S-HSW-1-HA

$12,243.84 each
$12,243.84 each
2

HySecurity Swing Gate Replacement Parts

HydraSwing 150 - HYDRA-SWING-150

HySecurity Power Unit for HydraSwing 150 Automatic Swing Gate Openers

Part: S-HSP-1-AG

$16,737.33 each
$16,737.33 each

Details

HySecurity HydraSwing 150 Swing Gate Operator (15,000 lbs Max.)

The HydraSwing 150 is HySecurity's most robust swing gate operator, purpose-built for oversized gates weighing up to 15,000 lbs. It is commonly deployed in correctional facilities, utility yards, and high-threat industrial zones where reliability and lifting capacity are paramount. This heavy-duty swing gate operator system uses a powerful hydraulic actuator and Smart Touch Controller for smooth, automated operation. As one of the most trusted swing gate operator solutions in high-security infrastructure, it's designed for extreme durability and control precision.

Key Features:

  • Heavy-duty swing gate operator system for oversized gates
  • Hydraulic actuator for high-strength and low-maintenance operation
  • Ideal for correctional facilities and secure industrial sites
  • Smart Touch Controller with 70+ programmable settings
  • Designed for the highest gate weight class in its category

Specifications:

  • Max gate weight: 15,000 lbs
  • Drive type: Hydraulic
  • Control system: Smart Touch with PC and network interface
  • Power input: 115/208/230V single-phase
  • Mount type: In-ground hydraulic system
  • Rated duty cycle: Continuous
  • Warranty: 5 years

Please Note: You will need a Drive Unit AND a Power Supply for this opener to function properly. When ordering, please also call to specify the voltage of your power supply OR you can click on the power supply and order it separately, where you can indicate the voltage. If you have any questions about what you may need, please review the order form below or Contact Us to consult with an expert. We are happy to assist. Order Form

HydraSwing Opener Model Comparison

Model HydraSwing 40 HydraSwing 40 Twin HydraSwing 40F HydraSwing 40F Twin HydraSwing 80F HydraSwing 150
Single or Twin Single leaf Twin (2 leaves) Single leaf Twin (2 leaves) Single leaf Single leaf
Open/Close Time 15-20 seconds, field adjustable 15-20 seconds, field adjustable 10-15 seconds, field adjustable 10-15 seconds, field adjustable 15-25 seconds, field adjustable 20-30 seconds, field adjustable
Gate Length Max. up to 24 ft (7.3 m) up to 16 ft (5 m) wide each leaf up to 16 ft (5 m) wide up to 16 ft (5 m) wide each leaf up to 30 ft (9 m) wide up to 40 ft (12 m) wide
Gate Weight Max. 4,000 lb (1,814 kg) 4,000 lb (1,814 kg) / leaf 4,000 lb (1,814 kg) 4,000 lb (1,814 kg) / leaf 8,000 lb (3,629 kg) 15,000 lb (6,804 kg)
ETL Listed (UL 325) Usage Class I, II, III, IV Usage Class III, IV
Warranty 5 year w/product registration
Prefer to Call? (888) 378-1127

Questions about part number HYDRA-SWING-150?

Required Fields *

Name *

Email *

Phone

My Questions *

SKU HYDRA-SWING-150
Operator Type HydraSwing
UL 325 Usage Class Class III, Class IV
Max. Gate Weight 15,000 lbs.
Drive Unit Voltage 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase), 240 AC (60 Hz, 3 Phase), 400 AC (50 Hz, 3 Phase), 460/480 AC (60 Hz, 3 Phase)
Max. Gate Length 40 ft
Finish Powder-Coated
Swing Gate Operators Single Leaf
Drive Type VFD Controlled Hydraulics
Duty Cycle Continuous Duty
Input Voltage 220/230/240 AC (60Hz, 1 Phase), 240 AC (60 Hz, 3 Phase), 208 AC (60Hz, 1 Phase), 208 AC (60Hz, 3 Phase), 460/480 AC (60Hz, 3 Phase)
Open/Close Time 15 to 25 Sec.
Specification Sheet Download PDF file
