HySecurity HydraSwing 80F Hydraulic Swing Gate Operator (Fast, 8,000 lbs Max.)

HySecurity HydraSwing 80F Hydraulic Swing Gate Operator (Fast, 8,000 lbs Max.)

HydraSwing 80F - HYDRA-SWING-80-F

HydraSwing 80F - HYDRA-SWING-80-F

HydraSwing 80F - HYDRA-SWING-80-F

HydraSwing 80F - HYDRA-SWING-80-F

HydraSwing 80F - HYDRA-SWING-80-F

HydraSwing 80F - HYDRA-SWING-80-F

Engineered for heavier gates and fast operation, the HydraSwing 80F supports single leaves up to 8,000 lbs. It's ideal for industrial yards, logistics hubs, and large facilities needing both speed and capacity. The system integrates seamlessly with high-security automation platforms.

Please Note: You will need a Drive Unit AND a Power Supply for this opener to function properly. When ordering, please also call to specify the voltage of your power supply OR you can click on the power supply and order it separately, where you can indicate the voltage. If you have any questions about what you may need, please review the order form below or Contact Us to consult with an expert. We are happy to assist. Order Form

1 Gate Opener Drive Units ↓
	HySecurity Drive Unit for HydraSwing 80F Automatic Swing Gate Openers Part: S-HSW-1-HE	$12,243.84 each $12,243.84 each

2 HySecurity Gate Power Supply ↓
	HySecurity HydraSupply Power Unit for HydraSwing 80F Automatic Swing Gate Opener Part: S-HSP-1-AF	$12,745.63 each $12,745.63 each

Details

HySecurity HydraSwing 80F Hydraulic Swing Gate Operator (Fast, 8,000 lbs Max.)

The HydraSwing 80F is a powerful, fast-cycle hydraulic swing gate operator designed for large, high-security gates up to 8,000 lbs. Its fast actuation makes it ideal for time-sensitive entry points at commercial freight depots, ports, and secure military installations. Built with an in-ground hydraulic gate drive and a Smart Touch Controller, it offers unmatched performance, configuration flexibility, and operational longevity. This model is part of HySecurity's heavy-duty swing gate operator system lineup built for industrial-grade automation.

Key Features:

Fast hydraulic swing gate opener for large, heavy gates
Industrial swing gate automation with Smart Touch interface
Supports up to 8,000 lbs gate weight
In-ground hydraulic gate drive with high torque output
Ideal for ports, defense facilities, and logistics centers

Specifications:

Max gate weight: 8,000 lbs
Drive type: In-ground hydraulic with fast actuation
Cycle type: Continuous duty
Controller: Smart Touch system with remote diagnostics
Power: 115/208/230V single-phase, 60 Hz
Environment: Outdoor-rated with corrosion-resistant chassis
Warranty: 5 years

Please Note: You will need a Drive Unit AND a Power Supply for this opener to function properly. When ordering, please also call to specify the voltage of your power supply OR you can click on the power supply and order it separately, where you can indicate the voltage. If you have any questions about what you may need, please review the order form below or Contact Us to consult with an expert. We are happy to assist. Order Form

HydraSwing Opener Model Comparison

Model	HydraSwing 40	HydraSwing 40 Twin	HydraSwing 40F	HydraSwing 40F Twin	HydraSwing 80F	HydraSwing 150
Single or Twin	Single leaf	Twin (2 leaves)	Single leaf	Twin (2 leaves)	Single leaf	Single leaf
Open/Close Time	15-20 seconds, field adjustable	15-20 seconds, field adjustable	10-15 seconds, field adjustable	10-15 seconds, field adjustable	15-25 seconds, field adjustable	20-30 seconds, field adjustable
Gate Length Max.	up to 24 ft (7.3 m)	up to 16 ft (5 m) wide each leaf	up to 16 ft (5 m) wide	up to 16 ft (5 m) wide each leaf	up to 30 ft (9 m) wide	up to 40 ft (12 m) wide
Gate Weight Max.	4,000 lb (1,814 kg)	4,000 lb (1,814 kg) / leaf	4,000 lb (1,814 kg)	4,000 lb (1,814 kg) / leaf	8,000 lb (3,629 kg)	15,000 lb (6,804 kg)
ETL Listed (UL 325)	Usage Class I, II, III, IV				Usage Class III, IV
Warranty	5 year w/product registration

Prefer to Call? (888) 378-1127

Questions about part number HYDRA-SWING-80-F?

Required Fields *

SKU	HYDRA-SWING-80-F
Operator Type	HydraSwing
UL 325 Usage Class	Class III, Class IV
Max. Gate Weight	8,000 lbs.
Drive Unit Voltage	208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase), 240 AC (60 Hz, 3 Phase), 400 AC (50 Hz, 3 Phase), 460/480 AC (60 Hz, 3 Phase)
Max. Gate Length	30 ft
Finish	Powder-Coated
Swing Gate Operators	Single Leaf
Drive Type	VFD Controlled Hydraulics
Duty Cycle	Continuous Duty
Input Voltage	220/230/240 AC (60Hz, 1 Phase), 240 AC (60 Hz, 3 Phase), 208 AC (60Hz, 1 Phase), 208 AC (60Hz, 3 Phase), 460/480 AC (60Hz, 3 Phase)
Open/Close Time	15 to 25 Sec.
Specification Sheet	Download PDF file
